I accept PayPal or VENMO. Cash on local pick up is fine too.
FREE Priority Mail shipping for USA!
This model is available in 5”, 8” and 12” stroke length. I don’t know which one this is. Any information would be appreciated.
These actuators are designed for 12V DC applications such as dump beds for utility vehicles, ATV and garden tractor attachments and implements, tilt trailers, jack plates and tilts for outboard motors, aircraft towing devices, trailer tongue jacks or any application that requires portable power. These proven actuators are shipped full of fluid, tested and ready for operation. For 120V AC applications, such as medical equipment, trash compactors, material handling, platform lifts, table lifts and many others, a convenient 120V AC adapter is available. ELIMINATES THE NEED FOR HYDRAULIC LINES The Model 7050 Hydraulic Actuator is completely self contained with its own fluid reservoir. It incorporates the pump, motor, reservoir, and cylinder all in the same housing, eliminating the need for hydraulic lines. CAN BE UTILIZED IN VIRTUALLY ANY ENVIRONMENT Model 7050 Actuator Specifications • • • • • • • • • • Motor Type: Permanent Magnet 12V DC Fluid capacity: 20 cu. in. (0.7 pint) Weight with Fluid: 12.5 lbs. Body: 6061 -T6511 Aluminum Alloy Rod: 6061 T6 Aluminum Hard Core Anodized Fasteners: 18-8 Stainless Steel Stroke Length: 5 in. Thrust (Extend): 5000 lbs. min. Thrust (Retract): 3750 lbs. min. Rate of Travel: 15 in. per minute The model 7050 Hydraulic Actuator is made of 100% non-ferrous materials and totally submersible. It contains a no-leak seal and wiper that keeps dirt and water out of the working parts. The Model 7050 Actuator shown above is available in 5” stroke length. 8” and 12” stroke actuators are also available. All CMC actuators include a 6’ cord set from the motor. For detailed information of all of our actuators, please go to our web site at www.cook-mfg.net/actuators
